A complete shape library — elbows, street elbows, tees, crosses and reducers — so any layout connects without makeshift joints.
Specifications
| Shapes | Elbow, tee, cross, reducer, union |
|---|---|
| Material | Brass, steel, stainless, aluminium |
| Size | 1/8" — 1" |
| Thread | NPT / BSP / BSPT / metric |
| Angle | 45° / 90° / 180° |
| Use | Layout & routing |
Selection Parameters
Typical operating ranges for this family — exact values are confirmed on the drawing / TDS before production.
| Thread | NPT / BSP / BSPT / metric |
|---|---|
| Material | Brass, steel, stainless, aluminium |
| Working pressure | Per request |
| Flow rate | Full bore (no flow restriction) |
| Temperature | -20 °C to +120 °C |
MOQ1000 pcs / item (mixed-SKU accepted)
CertificationNone yet (CE / ISO 9001 available on request)
Sample lead time3 – 5 days
Typical Applications
- Line routing
- Tight spaces
- OEM enclosures
- Retrofit
